T5K08, Laser Safety Goggles
Laser Safety Goggles, VLT 12%, for CO2, Diode, Fiber and Nd:YAG lasers
The T5K08 laser safety goggles use a purple thin-film glass filter with 12% visible light transmission (VLT) and protect against CO₂, Diode, Disk lasers. Supplied by Britton, Bengaluru, India.
Protection levels (optical density):
- OD 6+ @ 532 nm
- OD 3+ @ 850 - 900 nm
- OD 4+ @ 900 - 950 nm
- OD 5+ @ 950 - 1000 nm
- OD 7+ @ 1000 - 1600 nm
- OD 5+ @ 1600 - 2400 nm
- OD 5+ @ 2900 - 10600 nm
Always confirm that the optical density and wavelength range match your laser before use. Select a suitable frame from the datasheet.
Material: Thin-Film Glass
Color: Purple
VLT: 12%
Specification Sheet:
Common Laser Types: CO₂, Diode, Disk, Er:YAG, Fiber, Ho:YAG, KTP, Nd:YAG
Filter Specifications (OD): OD 6+ @ 532 nm, OD 3+ @ 850 - 900 nm, OD 4+ @ 900 - 950 nm,
OD 5+ @ 950 - 1000 nm, OD 7+ @ 1000 - 1600 nm, OD 5+ @ 1600 - 2400 nm,
OD 5+ @ 2900 - 10600 nm
Common Applications: Cutting, Dermatology, Drilling, Marking, Materials Processing, Military
Ophthalmology
Please select a suitable frame from the datasheet
